DOT Crack Chaser Blade

Price range: $45.00 through $55.00

V-segment diamond crack-chaser blade for routing concrete & asphalt cracks before repair, 4–5″.

Online card payments are not available at this time. Orders are taken by phone or by written quotation.

Request a Quote Call to Order (701) 922-1526

We confirm pricing, freight and lead time before any payment is requested.

Prices shown are current list prices and exclude freight and applicable sales tax. Pricing is confirmed in writing on your quote and is held for 30 days from the quote date. Prices and specifications are subject to change without notice.

Safety Never exceed the maximum operating speed marked on the blade. Check it against your saw's shaft speed before mounting. Use all guarding supplied with the machine, eye and hearing protection, and follow OSHA Table 1 dust controls for the task.

SKU: DOT-GRD-04
Category:
Brands:

Description

A sealant applied straight into a hairline crack fails, and it usually fails within a season. There is no width for the sealant to bond across and no clean substrate for it to bond to — just dust and loose edges. Routing the crack out first is what turns a repair into a repair that lasts.

The V-profile does the shaping

A crack chaser carries a V-shaped rim rather than a flat one, so a single pass follows the crack and leaves a tapered channel behind it. That taper is what the sealant needs: a wider mouth to bond into, clean sound concrete on both faces, and a reservoir deep enough that the sealant can flex as the slab moves through its thermal cycle instead of tearing away from the edge.

Sizes and where it gets used

Three sizes, 4″, 4.5″ and 5″, mounting on a standard angle grinder. Dry rated, medium bond, formulated for both concrete and asphalt — parking structure decks, warehouse floors before a coating goes down, slab-on-grade repairs, and pavement crack sealing ahead of an overlay.

Follow the crack rather than trying to straighten it, take one steady pass, then blow or vacuum the channel out completely before the sealant goes in. Any dust left in the groove becomes the bond line and the repair fails there. Related: the Tuck Point Blade for mortar joints.

Additional information

Blade Diameter

4", 4.5", 5"

Material

Asphalt, Concrete

Cutting Method

Dry

Bond Hardness

Medium

Segment Type

Segmented

Saw Fit

Angle Grinder

Grade

Professional
